Power Steering Columns

ESR Electric Steering Racks
KPS supplies a full range of premium quality remanufactured electric power steering columns. The range        includes: –

Alfa Mito
Citroen C1
Citroen C2
Citroen C3
Fiat Punto
Fiat Punto Grande
Fiat Evo
Fiat Stilo
Fiat Bravo
Fiat Panda
Fiat Seicento
Fiat Sedici
Fiat 500 & Abarth
Ford KA
Hyundai i10
Hyundai i20
Hyundai i30
Lancia Ypsilon
Mazda 2
Mercedes A Class
Mercedes B Class
Mitsubishi Colt
Nissan Micra Mk3
Peugeot 107
Peugeot 1007 MPV
Peugeot 207 Gen 1
Peugeot 207 Gen 2
Renault Clio Mk2
Renault Clio 3
Renault Megane Mk2
Renault Modus
Renault Scenic
Suzuki Alto
Suzuki Ignis
Suzuki SX4
Suzuki Wagon R
Suzuki Wagon R+
Toyota Aygo
Toyota Yaris
Vauxhall Agila
Vauxhall Combo C
Vauxhall Corsa B Mk2
Vauxhall Corsa C Mk3
Vauxhall Corsa D Mk4
Vauxhall Meriva Mk1
Vauxhall Tigra B (TT)
VW Golf Mk5 Gen 1
VW Golf Mk5 Gen 2
VW Golf Mk5 Gen 3

Some of the KPS power steering columns product range can be seen above. We have monthly product range extensions. If your particular application is not shown then please ‘contact us’ for availability.

Because EPS steering takes a completely different approach to conventional hydraulic steering systems, understanding and performance of EPS products needs to be approached in a completely different way.

At KPS our in-house quality standards and checks have been reviewed to accommodate EPS systems with training programs for distributors. In each sector of the aftermarket there is a lack of understanding regarding EPS column performance, fitting, standards, diagnostics, communication etc., and a responsibility lies with us, the remanufacturer, to support changes and solutions to everyone.

All of our EPS power steering columns are produced within the ISO9001 quality standards and our production standards means that all systems are quality checked at every stage of the remanufacturing process.

Identify column origins
Remove external components
Disassemble internal components
Deep clean all parts
Repair and replace components
Clean – paint frame/casings
Reassemble main components
Sync sensor to motor and ECU
Diagnostic check/analysis
Full test simulation manual
5 x full test simulations
Apply barcode and record data
Attach test report for customer
Label product with OE information
Packaged for secure dispatch to the customer

Our production processes are audited to ensure that all of our power steering columns meets only the highest standards.

Power steering Columns – Our Testing and Communication Process

Product test simulation is performed by syncing the EPS column to our test facilities. Communication between the EPS column and the ECU information electronically stored in the test environment and is performed using an OBDII cable, via the CAN wiring system.

Tests are performed with the engine switched off and on, with varying speed levels between 0 and 100kph. Braking assistance is also applied and can be adjusted to different resistances to simulate vehicle ride and feel.

The ability to simulate vehicles with City Mode is a feature of the test where applicable.

New distributors required
KPS now offer the full JTEKT HPI range of genuine Original Equipment electric and hydraulic power steering racks via our distributors throughout the UK and Europe. Contact KPS for distribution licenses in your country.

** All of our Power Steering Columns are supplied with a test certificate to prove their performance during test **
